Settle offers with the INCH Series a modern wall box that via OCPP interface and our app can load excess PV stream into your car from your solar system.
By integrating us, the wall box can be operated from anywhere and controlled intelligently.
Preparation
Around the Etrel INCH It is necessary to connect the OCPP backend to activate the Wallbox.
Before starting the furnishings, you have to use WiFi or LAN your wall box connect to the internet And install the latest updates.
To set up the OCCP backend, access via a web browser to the Wallbox is necessary.
Furnishings
Add a new wall box in the app and choose it Etrel INCH out of
If you put on the wallbox with us, then you will be your individual in the Wallbox menu OCPP-URL displayed.
Copy the OCPP-URL and put them in the Maxicharger altar

1. If the IP address of the Wallbox is not known:
a) ServicetĂ¼re Open on the left side of the wall box.
b) Service-Taster Press until a signal tone sounds.

The service menu is displayed on the screen.
c) in the service menu [1. Communication] choose:

The status of the individual interfaces is displayed.
d) Depending on the connection method (Ethernet or Wi-Fi) the corresponding Write down the IP address.

2. Start web browser (Chrome, Firefox, Edge, ...) Enter the WallBox IP address in the address line.

3. Enter access data.

The standard user name and that password are on one Stickers on the service door
4. Check firmware version:
Press the [≡] -> [Diagnose]


If the operating system version is older than 5.0.4 or the software version older than 5.3, you should make an update beforehand!
5. Open the configuration menu:
Press on it [≡] -> [configuration]

6. Menu item [User] and [Authorization for charging] open:

7. You can either be the type of authorization [Plug&Charge] Choose if the wall box is to be used without authentication.
On the other hand, if the wall box is freely accessible and it should not be used by everyone, you choose [Only local users].
Then you must not forget to create at least a local user!
After changing settings [Save] don't forget!
8. Open the menu for configuring the control center:
To do this, click on [Connectivity] -> [Connectivity of the control center]

9. Set the following settings:
A tick [✔] at [Activate communication with control center] set and with product type OCPP 1.6 JSON choose.

Characteristics of the charging station: This name will be displayed later in our app.
Control Center Endpunkt-URL: Copy address from our app
10. Open further settings (small arrow at the bottom right) and set the settings accordingly:

Do not forget the submenu regarding meter value types:
[Save] don't forget!
11. The settings only become effective after a restart.
Im Diagnostic Error 500 (Server Error)!!1500.That’s an error.There was an error. Please try again later.That’s all we know. Restart-Button.
